Ceia HIPE /PTZ-WP - Archway Dimensions and Mains Adapter

HI-PE multi-zone --- Rev. FI 050 GB 60K10 v2_1
7
Archway
This model is for the most part employed airports, ports, embassies, military installations, manufacturing
premises and stadiums. The panels are manufactured in exceptionally robust synthetic material.
The archway incorporates two bars which light up in the case of an alarm to show the height at which the
metal mass has been detected.
+ 115 (4"
1
/2)
2050 (80"
3
/4)
660 (26")
2255 (88"
3
/4)
+ 50 (2")
630 (24"
3
/4)
ø 6.5 (ø
1
/4")
t
EU
RX
TX
Standard Model
EU electronics unit
RX receiver panel
t cross-bar
TX transmitter panel
UW = 720mm (760mm or
820mm optional)
Fig. I-3a Dimensions
t
EU
TX
RX
UP
LP
Outdoor Model
(for outdoor
applications)
EU electronics unit
LP protection of the
lower connection
module
RX receiver panel
t cross-bar
TX transmitter panel
UP upper protection
UW =760mm
Fig. I-3b Dimensions
Mains adapter
Input voltage: 230Vac (CEE plug) or 115Vac /100Vac (UL plug)
Dimensions: 121 x 80 x 71 (LxWxH)
Cable length - plug side: 2m
Cable length - electronics unit side: 2m
Weight: 1,5 kg.
Protection degree: IP30
Fig. I-4
