Hardware Installation
Software Overview
The ORACLE is primarily operated using a touchscreen interface, although certain operations will be carried out by
the SMART 6 if it is being used for moisture analysis. This manual will only review the ORACLE software interface
and the SMART 6 screens that relate to the ORACLE analysis. Please refer to the SMART 6 manual for an overview
of the SMART 6 software screens.
Software Icons
Icon Description Icon Description Icon Description Icon Description
Accept Delete Main Menu QuikPrep
Temperature
Back Edit Tag Next Repeat Sample
Balance Connection Failing Value Passing Value SMART 6 Connection
Cancel Magnet Temperature Play/Start Sample Barcode Scanner
Login Screen
Upon boot up or activation from sleep mode, the software requires the user to login as either a Basic or Admin
user. This user access is part of the CFR Title 21 Part 11 compliance for tracking system actions by a signature
(in this case the login acts as the signature). User logins can be created for each individual using the ORACLE, or
shared between users. Both Basic and Administrator access is password protected.
