8.2.17. G-ULTRA to Vx SMART Controller
FIGURE 56
Vx SMART
Controller
GND IO4 NOIO1 NO COMIO2 COM
RELAY 1 RELAY 2
NCIO3 NC + VDC -
G-ULTRA
STATUS
+
COM
FRX PED TRG
Congurations in App
TRG (I1),
PED (I2),
GATE STATUS (IO4), or
FRX (IO5)
ELECTRICAL SETUPSECTION 8
8.2.18. Solar Panel
FIGURE 57
Vx SMART
Controller
Solar Regulator
*Battery: 33Ah - 200Ah
Specied
Solar Battery
*Solar Panels: 20W - 150W
*Solar Panel Brackets: 20W - 150W
