1. INTRODUCTION
The VANTAGE SMART linear swing gate motor, available in two models with actuation
strokes of 400mm and 500mm, respectively, has been designed to automate a wide variety
of swing gates, from single or double light-domestic gates to heavy industrial double swing
gates.
The fail-safe and fully-redundant Position and Collision Detection System has been designed
and tested to set the standard in safety of operation and to provide an unparalleled level of
reliability and durability in operation.
The gate Travel Limits are managed by a sealed opto-electronic system that has been
designed not only to ensure ultra-reliable operation, but also to ensure precise position and
trajectory control. This enables very accurate and reliable collision detection to ensure safe
operation even under trying conditions.
This guide covers the mechanical installation of your new VANTAGE SMART swing gate
operator.
Advanced features of the Vx SMART logic controller include:
• Interactive graphic user interface via a smartphone application
• Automated setup of gate endpoints (limits)
• Independently-adjustable motor speed in both opening and closing directions
• Fail-safe collision detection and auto-reverse (adjustable sensitivity)
• Smooth, adjustable start/stop (ramp-up/ramp-down)
• Multiple operational modes
• Selectable, adjustable Autoclose
• Pedestrian (partial) opening
• Positive Close Mode
• Supports up to three sets of Photon SMART Safety beams
• Independent safety inputs for opening and closing beams (wired)
• Automatic beam test for both opening and closing beams (wired)
• Advanced lightning/surge protection
• Onboard NOVA code-hopping radio receiver with full channel-mapping capability
(1500 MyCentsys Remote users
1)
1. Multiple buttons per remote can be used.
VANTAGE SMART swing gate operators can be installed on both inward-
and outward-opening swing gates. Please see the relevant sections for
each type of installation, paying attention to any site preparation that
needs to be made before the operators are installed.
