1. In the case of the wiring being mounted externally, knock
out the tab in the base of the cover (1) to allow the cable to
pass through.
2. If the keypad is to be mounted
on a gooseneck, or if the cable
must pass through the centre
of the back panel, knock out
the tab (2).
3. In both the above cases,
ensure the cable entry points
are sealed with silicon sealant.
23
GOOSENECK
CABLE ROUTE
INTERNAL WIRING
CABLE ROUTE
EXTERNAL WIRING
CABLE ROUTE
1
2
To Next Page
