24
Fitting the optional anti-tamper switch
1. Solder the wires from an alarm system to the relevant
contacts on the anti-tamper switch.
2. Slide the anti-tamper switch into the switch carrier. Ensure
that the retaining pins in the switch carrier pass through the
matching holes in the switch.
3. Slide the switch and carrier assembly into the grooves
provided in the keypad cover.
3
2
1
TO 3rd PARTY
ALARM SYSTEM
