SECTION 9 OPERATOR INSTALLATION - INWARD OPENING GATES
Example: 90° Inward Opening gate (VANTAGE 400):
Assume that the E-Value has been measured as 160mm. By looking at this
Table at E-Values that are smaller than (<) 165mm, the relevant A- and
B-Values are: A=145mm and B=240mm.
E-Value
Depth of gate hinge
to pillar
A-Value B-Value
<165mm 145mm 240mm
<175mm 130mm 250mm
