Centurion Vantage - VANTAGE 400 Inward Opening Tables

page 29www.CentSys.com
SECTION 9
VANTAGE 400 Inward Opening Gate Geometry Tables:
90° Inward Opening Gate
E-Value
Depth of gate hinge
to pillar
A-Value B-Value
<145mm
1
170mm
1
220mm
1
<155mm 160mm 230mm
<165mm 145mm 240mm
<175mm 130mm 250mm
100° Inward Opening Gate
E-Value
Depth of gate hinge
to pillar
A-Value B-Value
<125mm
1
165mm
1
200mm
1
<135mm 155mm 210mm
<145mm 145mm 220mm
<155mm 135mm 230mm
1. Optimum Installation
TABLE 11
1. Optimum Installation
TABLE 10
1. Optimum Installation
TABLE 12
110° Inward Opening Gate
E-Value
Depth of gate hinge
to pillar
A-Value B-Value
<115mm
1
155mm
1
190mm
1
<125mm 145mm 200mm
<135mm 140mm 210mm
<145mm 130mm 220mm
OPERATOR INSTALLATION - INWARD OPENING GATES
