SECTION 9
VANTAGE 500 Inward Opening Gate Geometry Tables:
90° Inward Opening Gate
E -Value
Depth of gate hinge
to pillar
A-Value B-Value
<190mm
1
205mm
1
280mm
1
<205mm 195mm 290mm
<215mm 180mm 300mm
<225mm 170mm 310mm
<235mm 155mm 320mm
<245mm 140mm 330mm
TABLE 13
1. Optimum Installation
100° Inward Opening Gate
E-Value
Depth of gate hinge
to pillar
A-Value B-Value
<175mm
1
195mm
1
260mm
1
<185mm 185mm 270mm
<195mm 175mm 280mm
<205mm 165mm 290mm
<215mm 155mm 300mm
<225mm 145mm 310mm
<235mm 135mm 320mm
TABLE 14
1. Optimum Installation
OPERATOR INSTALLATION - INWARD OPENING GATES
