VANTAGE 500 Inward Opening Gate Geometry Table:
110° Inward Opening Gate
E-Value
Depth of gate hinge
to pillar
A-Value B-Value
<150mm
1
190mm
1
240mm
1
<160mm 185mm 250mm
<170mm 175mm 260mm
<180mm 170mm 270mm
<190mm 160mm 280mm
<205mm 150mm 290mm
<210mm 145mm 300mm
<220mm 135mm 310mm
<230mm 125mm 320mm
TABLE 15
1. Optimum Installation
OPERATOR INSTALLATION - INWARD OPENING GATES
