Cervis TM70 - Figure 11. TX Pushbutton;Switch Numbers;Names; Table 6. Transmitter Layout

TM70 Handheld Wireless Remote Control
U003.6.0-TM70_HH_SYS-R
18
Table 6. Transmitter Layout
Ref.
Component
Ref.
Component
1
IR Range
Limiter
(optional)
7
Warning/Start
switch
2
LCD
(optional)
8
CAT3 Stop
switch
3
Diagnostic
LED
9
Shock
absorbers
4
Two-step
pushbuttons
10
Portable
EEPROM
5
Maintained or
spring return
switch
11
Battery
6
Safety key switch
Figure 11. TX Pushbutton/Switch Numbers/Names
