TM70 Handheld W
ireless Remote Control
U003.6.0-TM70_H
H_SYS-R
4
Table 2. T
M70 Main Specifications
TM70
Frequency band
914.150
–
915.875
MHz
ERP < 1mW
Response Time
100 ms
Temperature Rang
e
0 to 150 °F (-20 t
o 65 °C)
T70/1 and T
70/2 Transmitters
Protection
IP65
R70/13 and R70
/21 Receiv
ers
Power Supply
48, 115, 230 VAC ± 1
0%
--
50/60 H
z
Optional
12 or 24 VDC
Consumption
20 mW
Relays
230
VAC/8
A
STOP Relays
230
VAC/6
A
Protection
IP
65
Electrical Securit
y
Class II (EN50178)
CB70 Battery
Charger
Power Supply
12/24 VDC, 115
VAC
BTO6K Batteries
Voltage
4.8 V
Capacity
750 mAh NiMH
Charging Temperatur
e
+41 to +95°F (0 to 3
5°C
)
Battery Life
16 hrs. @ 15% du
ty cycle
7
9
Table of Contents
Default Chapter
3
Table of Contents
3
Welcome to Cervis
5
Figure 1. TM70 System Components with a TM70/1 Transmitter
6
1 TM70 System Description
6
Figure 2. TM70/2 Transmitter Layout
7
Table 1. TM70/02 Transmitter Component Descriptions
7
Table 2. TM70 Main Specifications
8
2 Safety Instructions
9
What You MUST Do
9
What You MUST NOT Do
9
3 System Component Installation
11
Transmitter Battery
11
CB70 Battery Charger
13
Figure 3. CB70 Battery Charger
13
Charging Tips
14
Figure 4: Typical MOV Wiring Across Contactor Coil
14
Receiver Installation
14
Figure 5. Receiver Footprint
15
Figure 6. Receiver Antenna with Extension Kit
15
Figure 7. Main Board Connections, Relays, and Leds
16
Starting up
17
Table 3. Receiver LED States During Power-Up
17
Figure 8. TM70 Transmitter Details
18
Table 4. Receiver Leds Upon Receiving a Transmitter Signal
18
4 Using the System
19
Battery Level Monitor
19
LCD Option Power Level Display
20
General Instructions
19
Programming a Spare Transmitter
20
Transfer EP70 from Transmitter to Spare Transmitter
20
Table 5. LCD Power Level Interpretation
20
Copy Receiver EP70 to Transmitter EP70
21
Figure 9. Extracting the EP70 Memory Module
21
Figure 10. Receiver EP70 Module Location
21
Figure 11. TX Pushbutton/Switch Numbers/Names
22
Table 6. Transmitter Layout
22
Figure 12. Transmitter Button Locations
23
Figure 13. Range Limiter Application Examples
26
Figure 14. IR Limiter Working Area
27
Technical Characteristics of the LA70
28
Table 7. Transmitter Status LED Fault Identification
29
Returning Equipment for Repair
30
Infrared Transmitter
27
Installation
27
Programming the Machine Identification in LCD Transmitters
23
LCD Display Analog Feedback Calibration
24
Calibrating Analog Feedback
24
Range Limiter
25
Infrared Sensor
26
5 Maintenance
29
Fault Identification
29
Transmitter
29
Receiver
29
Precautions
29
Table 8. Receiver Status LED Fault Identification
30
Table 9.Available Spare Parts
31
Common Spare Parts Identification (Limited)
33
Spare Parts
31
Figure 15. TM70/1 2301090 Pushbutton Transmitter
33
Figure 16.TM70/2 2301091 Pushbutton Transmitter
33
Figure 17. TM70/1 2301090-B4-DLA Display Handheld Transmitter
34
Figure 18. TM70/1 2301091-B4-DLA Display Handheld Transmitter
34
Figure 19. PS70/1 DLA Upper 2303801 and PS70/2 DLA Upper 2303811
35
6 Warranty
36
