Cervis TM70 User Manual

TM70 Handheld Wireless Remote Control
U003.6.0-TM70_HH_SYS-R
2
1.0 TM70 System Description
A standard TM70 system is comes complete with:
 One (1) Transmitter – either a TM70/1 or a TM70/2
 One (1) R70 Receiver
 One (1) CB70 Battery Charger
 Two (2) BT06K Batteries
 One (1) Antenna (internal or external)
The battery operated TM70/1 and TM70/2 push-button style transmitters are designed
for the remote control of industrial equipment. An operator using a handheld transmitter
can determine the safest location from which to carry out an operation. The receiver is
connected to the electrical system of the machine to be operated. Table 2 below lists
the Main Specifications of the TM70 system.
Figure 1. TM70 System Components with a TM70/1 Transmitter
Transmitter
Receiver
CB70 Charger with Batteries
