CET PMC-340 User Manual

CET Inc.
37
Register
Property
Description
Format
Scale
Unit
3000
RO
Ia
Float
x1
A
3002
RO
Ib
Float
3004
RO
Ic
Float
3006
RO
kW Total
Float
W
3008
RO
kvar Total
Float
var
3010
RO
kVA Total
Float
VA
Table 5-11 Present Demand Measurements
5.5.2 Peak Demand Log of This Month (Since Last Reset)
Register
Property
Description
Format
Scale
Unit
3400~3405
RO
Ia
See
Table 5-15
Demand Data
Structure
x1
A
3406~3411
RO
Ib
3412~3417
RO
Ic
3418~3423
RO
kW Total
W
3424~3429
RO
kvar Total
var
3430~3435
RO
kVA Total
VA
3436~3441
RO
kW Total of T1
W
3442~3447
RO
kvar Total of T1
var
3448~3453
RO
kVA Total of T1
VA
3454~3459
RO
kW Total of T2
W
3460~3465
RO
kvar Total of T2
var
3466~3471
RO
kVA Total of T2
VA
3472~3477
RO
kW Total of T3
W
3478~3483
RO
kvar Total of T3
var
3484~3489
RO
kVA Total of T3
VA
3490~3495
RO
kW Total of T4
W
3496~3501
RO
kvar Total of T4
var
3502~3507
RO
kVA Total of T4
VA
Table 5-12 Peak Demand Log of This Month
5.5.3 Peak Demand Log of Last Month (Before Last Reset)
Table 5-13 Peak Demand Log of Last Month
Notes:
1) The following table illustrates Demand Data Structure:
Offset
Description
+0
High
Year - 2000
Low
Month
+1
High
Day
Low
Hour
+2
High
Minute
Low
Second
Register
Property
Description
Format
Scale
Unit
3600~3605
RO
Ia
See
Table 5-15
Demand Data
Structure
x1
A
3606~3611
RO
Ib
3612~3617
RO
Ic
3618~3623
RO
kW
W
3624~3629
RO
kvar
var
3630~3635
RO
kVA
VA
3636~3641
RO
kW Total
W
3642~3647
RO
Kvar Total
var
3648~3653
RO
kVA Total
VA
3654~3659
RO
kW Total of T1
W
3660~3665
RO
kvar Total of T1
var
3666~3671
RO
kVA Total of T1
VA
3672~3677
RO
kW Total of T2
W
3678~3683
RO
kvar Total of T2
var
3684~3689
RO
kVA Total of T2
VA
3690~3695
RO
kW Total of T3
W
3696~3701
RO
kvar Total of T3
var
3702~3707
RO
kVA Total of T3
VA
