CET PMC-340 User Manual

CET Inc.
43
Table 5-23 SOE Classification
5.9 Data Recorder Log (PMC-340B Only)
Register
Property
Description
Format
Note
20000
RW
Data Recorder Log Number
1
UINT32
20002
RO
High-order Byte: Year
UINT16
1 to 99 (Year-2000)
Low-order Byte: Month
1 to 120
20003
RO
High-order Byte: Day
UINT16
1 to 28/29/30/31
Low-order Byte: Hour
0 to 23
20004
RO
High-order Byte: Minute
UINT16
0 to 59
Low-order Byte: Second
0 to 59
20005
RO
Millisecond
UINT16
20006~20007
RO
Parameter 1
Float
20008~20009
RO
Parameter 2
Float
20010~20011
RO
Parameter 3
Float
20012~20013
RO
Parameter 4
Float
20014~20015
RO
Parameter 5
Float
20016~20017
RO
Parameter 6
Float
20018~20019
RO
Parameter 7
Float
20020~20021
RO
Parameter 8
Float
20022~20023
RO
Parameter 9
Float
20024~20025
RO
Parameter 10
Float
20026~20027
RO
Parameter 11
Float
20028~20029
RO
Parameter 12
Float
20030~20031
RO
Parameter 13
Float
6
None
0
Clear 3-Phase Energy registers and
Phase A/B/C Energy registers via
Communication
7
None
0
Clear Monthly Energy Log of The
Preset Month via Communication
8
None
0
Clear 3-Phase Total Energy registers
and Phase A/B/C Energy Registers,
Monthly Energy Log of the Last 12
Months and Monthly Energy Log of the
Present Month via Front Panel
9
None
0
Clear Peak Demand Logs of This Month
(Since Last Reset) via Communication
10
None
0
Clear all Peak Demand Logs and
Present Demand via Communication
11
None
0
Clear All Peak Demand Logs and
Present Demand via Front Panel
12
None
0
Clear Max./Min. Log of This Month
(Since Last Reset) via Communication
13
None
0
Clear All Max./Min. Log
via Communication
14
None
0
Clear all Max./Min. Log
via Front Panel
15
None
0
Clear Device Operating Time via
Communication
16
None
0
Clear All Records via Communication,
including 3-Phase Total Energy and
Phase A/B/C Energy Registers, Monthly
Energy Log of the Last 12 Months,
Monthly Energy Log of the Present
Month, all Max./Min. Log, all Demand
Log, Device Operating Time, DIx Pulse
Counters, DR Log and SOE
17
None
0
Clear DI1 Pulse Counter
via Communication
18
None
0
Clear DI2 Pulse Counter
via Communication
19
None
0
Clear DI3 Pulse Counter
via Communication
20
None
0
Clear DR Logs via Communication
21
None
0
Clear SOE Logs via Communication
22
None
0
Clear All DI Counters via Front Panel
