CET PMC-340 User Manual

CET Inc.
38
+3
-
Millisecond
+4~+5
-
Record Value
Table 5-14 Demand Data Structure
5.6 Max./Min. Log
5.6.1 Max. Log of This Month (Since Last Reset)
Register
Property
Description
Format
Scale
Unit
4000~4005
RO
Uan
See 5.6.5
Max./Min. Log
Structure
x1
V
4006~4011
RO
Ubn
4012~4017
RO
Ucn
4018~4023
RO
Uln Average
4024~4029
RO
Uab
4030~4035
RO
Ubc
4036~4041
RO
Uca
4042~4047
RO
Ull Average
4048~4053
RO
Ia
A
4054~4059
RO
Ib
4060~4065
RO
Ic
4066~4071
RO
I Average
4072~4077
RO
kWa
W
4078~4083
RO
kWb
4084~4089
RO
kWc
4090~4095
RO
kW Total
4096~4101
RO
kvara
var
4102~4107
RO
kvarb
4108~4113
RO
kvarc
4114~4119
RO
kvar Total
4120~4125
RO
kVAa
VA
4126~4131
RO
kVAb
4132~4137
RO
kVAc
4138~4143
RO
kVA Total
4144~4149
RO
PFa
-
4150~4155
RO
PFb
4156~4161
RO
PFc
4162~4167
RO
PF Total
4168~4173
RO
Frequency
Hz
4174~4179
RO
I4
A
4180~4185
RO
Uan/Uab THD
-
4186~4191
RO
Ubn/Ubc THD
4192~4197
RO
Ucn/Uca THD
4198~4203
RO
Ia THD
4204~4209
RO
Ib THD
4210~4215
RO
Ic THD
4216~4221
RO
Ia K-factor
4222~4227
RO
Ib K-factor
4228~4233
RO
Ic K-factor
4234~4239
RO
Ia Crest-factor
4240~4245
RO
Ib Crest-factor
4246~4251
RO
Ic Crest-factor
4252~4257
RO
Voltage Unbalance
4258~4263
RO
Current Unbalance
Table 5-15 Max. Log of This Month (Since Last Reset)
5.6.2 Min. Log of This Month (Since Last Reset)
Register
Property
Description
Format
Scale
Unit
4300~4305
RO
Uan
See 5.6.5
Max./Min. Log
Structure
x1
V
4306~4311
RO
Ubn
4312~4317
RO
Ucn
4318~4323
RO
Uln Average
4324~4329
RO
Uab
4330~4335
RO
Ubc
