48
24
RW
Season #7: Start Date
UINT16
See Season #2: Start Date
25
RW
Season #7: Weekday#1 Daily Profile
UINT16
0 to 19
26
RW
Season #7: Weekday#2 Daily Profile
UINT16
27
RW
Season #7: Weekday#3 Daily Profile
UINT16
28
RW
Season #8: Start Date
UINT16
See Season #2: Start Date
29
RW
Season #8: Weekday#1 Daily Profile
UINT16
0 to 19
30
RW
Season #8: Weekday#2 Daily Profile
UINT16
31
RW
Season #8: Weekday#3 Daily Profile
UINT16
32
RW
Season #9: Start Date
UINT16
See Season #2: Start Date
33
RW
Season #9: Weekday#1 Daily Profile
UINT16
0 to 19
34
RW
Season #9: Weekday#2 Daily Profile
UINT16
35
RW
Season #9: Weekday#3 Daily Profile
UINT16
36
RW
Season #10: Start Date
UINT16
See Season #2: Start Date
37
RW
Season #10: Weekday#1 Daily Profile
UINT16
0 to 19
38
RW
Season #10: Weekday#2 Daily Profile
UINT16
39
RW
Season #10: Weekday#3 Daily Profile
UINT16
40
RW
Season #11: Start Date
UINT16
See Season #2: Start Date
41
RW
Season #11: Weekday#1 Daily Profile
UINT16
0 to 19
42
RW
Season #11: Weekday#2 Daily Profile
UINT16
43
RW
Season #11: Weekday#3 Daily Profile
UINT16
44
RW
Season #12: Start Date
UINT16
See Season #2: Start Date
45
RW
Season #12: Weekday#1 Daily Profile
UINT16
0 to 19
46
RW
Season #12: Weekday#2 Daily Profile
UINT16
47
RW
Season #12: Weekday#3 Daily Profile
UINT16
Table 5-31 Season Setup
Notes:
1) Start Date for Season #1 is Jan. 1
st
and cannot be modified.
2) Setting a Season’s Start Date as 0xFFFF terminates the TOU’s Season settings. All subsequent
Seasons’ setup parameters will be ignored since the previous Season’s duration is from its Start
Date to the end of the year.
3) The Start Date of a particular Season must be later than the previous Season’s.
5.12.3 Daily Profile
The PMC-340 has two sets of Daily Profile setup parameters, one for each TOU.
Register Address
Property
Description
Format
7200~7223
RW
Daily Profile #1
See Table 5-34
Daily Profile Data
Structure
7224~7247
RW
Daily Profile #2
7248~7271
RW
Daily Profile #3
7272~7295
RW
Daily Profile #4
7296~7319
RW
Daily Profile #5
7320~7343
RW
Daily Profile #6
7344~7367
RW
Daily Profile #7
7368~7391
RW
Daily Profile #8
7392~7415
RW
Daily Profile #9
7416~7439
RW
Daily Profile #10
7440~7463
RW
Daily Profile #11
7464~7487
RW
Daily Profile #12
7488~7511
RW
Daily Profile #13
7512~7535
RW
Daily Profile #14
7536~7559
RW
Daily Profile #15
7560~7583
RW
Daily Profile #16
7584~7607
RW
Daily Profile #17
7608~7631
RW
Daily Profile #18
7632~7655
RW
Daily Profile #19
7656~7679
RW
Daily Profile #20
Table 5-32 TOU #1’s Daily Profile Setup
Register Address
Property
Description
Format
8200~8223
RW
Daily Profile #1
See Table 5-34
Daily Profile Data Structure
8224~8247
RW
Daily Profile #2
8248~8271
RW
Daily Profile #3
8272~8295
RW
Daily Profile #4
8296~8319
RW
Daily Profile #5
