8. Dismantling of parts
8.1 Parts on the door
Door seal
Door seal is installed into door liner groove.
1)Open the refrigerator door;
2)Take the door seal ① out of door liner;
Door tray
While squeezing it inward, lift up the baffle and take it out
from refrigerator liner.
Door stopper
Door stopper
None
rollover beam
rollover beam
None
8.2 Parts inside the refrigerator
Shelves
1）Lift up the division plate with a proper force and pull it
out towards yourself;
Drawer
Drawer
None
8.3 Light system
