8.8 Display control board
Display control board
Refer to the method of disassembling. Light
8.9 Main control board
Main control board
1) Loosen the 2 screws on the mounting box with a
Phillips screwdriver;
2) Open the cover with a flat screwdriver;
3) Press the latch outward to remove Main control boardl
8.10 Bar counter
Bar counter
Disassembly and installation of bar counter
None
Disassembly and installation bar doorseal
None
