Disassembly and installation of Air duct
The cold room lamp is in the cold room air duct compon
ent1) Pry open the lampshade with a blade
2) Remove 1 fixed screw with a cross screwdriver
There is a light switch on the side wall of the refrigerating
chamber.
1）Loosen the hook with small normal screwdriver and
pull out the switch until the wire connector reveals.
8.4
Air duct components refrigerating chamber
Air duct components refrigeratingchamber
Use the blade to pry open the lamp cover,remove one
setscrew with a Phillips screwdriver, remove the air
components duct from the bottom
8.5
Air duct components in freezing chamber and fan motor
