Challenger Lifts 4P14EFX - Component Part Numbers

Model 4P14 Flat Deck, Closed Front
Installation, Operation and Maintenance
15 Rev 08/11/17
4P14-X-IOM-A.doc
ITEM # PART # QTY/LIFT DESCRIPTION
1
B44011
1 HYDRAULIC CYLINDER
2 B40082 1 CLEVIS PIN
3 B40126 5 1/8 x 1 1/2" Lg. COTTER PIN
4
JZQ7-07-01-00
1
FLAT DECK POWER RUNWAY (4P14E)
JZQ7A-07-01-00 FLAT DECK POWER RUNWAY (4P14X)
5
JZQ7-08-01-00
1
FLAT DECK IDLER RUNWAY (4P14E)
JZQ7A-08-01-00
FLAT DECK IDLER RUNWAY (4P14X)
6 B40266 2 WHEEL STOP
7 B40083 8 M12 x 35mm Lg. HEX.FLG.HD.CAP SCREW
8 JZQ7-04-01-00 1 CROSS BEAM ASSEMBLY
9 B40265 2 WHEEL CHOCK
10
AB-9367-DLH
1
POWER UNIT 1 PHASE, 60Hz, 208-230VAC
AD-9367
POWER UNIT 3 PHASE, 230/460VAC
11 B40449-P 1 POWER COLUMN ASSEMBLY
12 B40449-I 3 IDLER COLUMN ASSEMBLY
13 JZQ7-06-01-00 2 ENTRANCE RAMP
14 B40165 2 RAMP HINGE PIN
15 40168 2 RAMP SLIDE
16
31062
6 1/4-20NC x 3/4" Lg. PAN HEAD SCREW
17 40085 6 1/4-20NC HEX FLANGE NUT
18 A2128 1 45 DEGREE ADAPTER ELBOW - MALE #6 O-RING x MALE #6 JIC 37 deg
19 B16167 1 90 DEGREE ADAPTER ELBOW - MALE #6 O-RING x MALE #6 JIC 37 deg
20 B40349 1 HYDRAULIC HOSE – FEMALE #6 J.I.C. BOTH ENDS
21 B40452 4 LADDER WELD
22
B40130
4 M20 HEX JAM NUT
23 B40129 4 M20 HEX NUT
Replace all worn, damaged, or broken parts with parts approved by Challenger Lifts Inc.
or with parts meeting Challenger Lifts Inc. specifications.
Contact your local Challenger Lifts Parts Distributor for pricing and availability.
(Call Challenger Lifts Inc. (502) 625-0700 for the Parts Distributor in your area)
