Model 4P14 Flat Deck, Closed Front
Installation, Operation and Maintenance
17 Rev 08/11/17
4P14-X-IOM-A.doc
PARTS BREAKDOWN (continued)
Fig C. Runway Sheaves
ITEM #
PART # QTY/LIFT
DESCRIPTION
1
B40650 10
SHEAVE
2
B40053 11
1/8” THICK BEARING
3
B40055 4
SHEAVE PIN (RUNWAY)
4
B31188
16
M8 x 16mm Lg HEX LOCKING FLANGE HEAD CAP SCREW
5
B40438-R 1
RUNWAY SHEAVE SPACER, 2 1/8”
Replace all worn, damaged, or broken parts with parts approved by Challenger Lifts Inc.
or with parts meeting Challenger Lifts Inc. specifications.
Contact your local Challenger Lifts Parts Distributor for pricing and availability.
(Call Challenger Lifts Inc. (502) 625-0700 for the Parts Distributor in your area)
