Chamberlain K001D8395 - Medium Duty Logic Operator

61
26
ANT
J2
AUX ANT
COM INTRLK STOP
LED
OPENCLOSE
TTC
LEARN
1
LMEP1 LMEP2
2345 67
STOP CLOSE OPEN
OPEN
CLOSE
STOP
Brake (BMT only)
Capacitor
Motor
Safety Limit
Switch
Open Limit
Switch
Close Limit
Switch
Yellow
Red
Grey
Purple
Orange
Grey
Yellow
Brown**
Brown**
Black
Black
Green
L2
L1
Red
Yellow
Blue*
White*
* seriw ,deilppus ton si ekarB fI
are capped separately
**
Remove Jumper to Install
External Door Interlock.
If Interlock is not
used, wires are
capped together.
F
Wiring Diagrams
Medium Duty Logic Operator
