8
Warning Sign
Primary Operator
Control Box
Photoelectric Sensors
Photoelectric Sensors
Junction
Box
Secondary Operator
Warning Sign
Control Box
Earth Ground Rod
Check national and local
codes for proper depth
Photoelectric
Sensors
Operator
NOTE: One or more non-contact
sensors shall be located where the risk of
entrapment or obstruction exists at either the
opening or closing direction. Care shall be
exercised to reduce the risk of nuisance
tripping, such as when a vehicle, trips the
sensor while the gate is still moving.
OVERVIEW OF TYPICAL INSTALLATION
INTRODUCTION
Identify your installation type (refer to the Appendix in the back of the manual for more information). All the illustrations on the following pages
display a typical Left-Hand Gate installation with a pull-to-open bracket. For Push-to-Open applications refer to the Appendix.
DUAL GATE
SINGLE GATE
Photoelectric
Sensors
Photoelectric
Sensors
Photoelectric Sensors
Warning Sign
Photoelectric
Sensors
Earth Ground Rod
Check national and local
codes for proper depth
Edge Sensors
Edge Sensor
Edge Sensor
Water Tight Conduit (Not provided)
NOTE: Power and control wiring
MUST be run in separate conduits.
Water Tight Conduit (Not provided)
NOTE: Power and control wiring
MUST be run in separate conduits.
