6.7 CUA-24HVR4
MODEL
CUA-24HVR4
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºC W
15ºC D
14ºC W
7ºC D
6ºC W
3ºC D
2ºC W
-5ºC D
-6ºC W
-7ºC D
-8ºC W
-14ºC D
-15ºC W
15ºC
Capacity kW
7.95
7.83
7.81
7.58
7.25
7.14
6.43
Input kW.
2.08
1.97
1.92
1.89
1.85
1.84
1.75
18ºC
Capacity kW
7.90
7.78
7.75
7.53
7.20
7.09
6.39
Input kW.
2.11
2.01
1.95
1.92
1.88
1.87
1.78
20ºC
Capacity kW
7.86
7.73
7.70
7.47
7.15
7.04
6.35
Input kW.
2.17
2.04
1.98
1.96
1.92
1.90
1.81
22ºC
Capacity kW
7.82
7.67
7.65
7.42
7.10
6.99
6.30
Input kW.
2.21
2.08
2.02
1.99
1.95
1.94
1.84
27ºC
Capacity kW
7.73
7.62
7.59
7.37
7.05
6.94
6.26
Input kW.
2.26
2.12
2.06
2.03
1.99
1.97
1.88
6.8 CUA-36HVR4, CUA-36HVR4S
MODEL
CUA-36HVR4, CUA-36HVR4S
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºC W
15ºC D
14ºC W
7ºC D
6ºC W
3ºC D
2ºC W
-5ºC D
-6ºC W
-7ºC D
-8ºC W
-14ºC D
-15ºC W
15ºC
Capacity kW
12.11
11.70
11.66
11.32
10.83
10.67
9.61
Input kW.
3.61
3.38
3.28
3.24
3.17
3.15
3.01
18ºC
Capacity kW
12.08
11.62
11.58
11.24
10.75
10.59
9.54
Input kW.
3.65
3.44
3.35
3.31
3.23
3.21
3.06
20ºC
Capacity kW
12.04
11.54
11.50
11.16
10.68
10.52
9.48
Input kW.
3.71
3.51
3.40
3.36
3.29
3.27
3.12
22ºC
Capacity kW
12.00
11.46
11.42
11.09
10.60
10.44
9.41
Input kW.
3.77
3.56
3.46
3.42
3.35
3.33
3.16
27ºC
Capacity kW
11.73
11.38
11.34
11.01
10.53
10.37
9.35
Input kW.
3.87
3.63
3.53
3.48
3.41
3.38
3.23
6.9 CUA-48HVR4,CUA-48HVR4S
MODEL
CUA-48HVR4, CUA-48HVR4S
HEATING
OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºC W
15ºC D
14ºC W
7ºC D
6ºC W
3ºC D
2ºC W
-5ºC D
-6ºC W
-7ºC D
-8ºC W
-14ºC D
-15ºC W
15ºC
Capacity kW
15.59
15.46
15.41
14.97
14.30
14.09
12.52
Input kW.
5.40
4.90
4.79
4.72
4.61
4.58
4.36
18ºC
Capacity kW
15.43
15.35
15.30
14.87
14.22
13.99
12.62
Input kW.
5.51
5.00
4.87
4.79
4.68
4.65
4.43
20ºC
Capacity kW
15.35
15.25
15.20
14.76
14.12
13.91
12.52
Input kW.
5.58
5.07
4.97
4.90
4.79
4.75
4.54
22ºC
Capacity kW
15.28
15.15
15.10
14.66
14.01
13.81
12.44
Input kW.
5.68
5.19
5.04
4.97
4.87
4.83
4.61
27ºC
Capacity kW
14.94
15.05
14.99
14.56
13.91
13.71
12.34
Input kW.
5.79
5.26
5.11
5.04
4.97
4.94
4.68
