6. Capacity Table
Cooling
6.1 CCR-18HVR4
MODEL
CCR-18HVR4
COOLING
OUTDOOR TEMPERATURE DRY
Indoor Conditions
21ºC
25
28ºC
32ºC
35ºC
42ºC
49 ºC
21ºC D
15ºC W
Total capacity kW
5.09
5.06
5.04
5.01
4.99
4.93
4.88
Input kW.
1.49
1.50
1.51
1.53
1.54
1.62
1.70
24ºC D
17ºC W
Total capacity kW
5.25
5.22
5.20
5.17
5.15
5.09
5.03
Input kW.
1.51
1.52
1.53
1.55
1.56
1.64
1.72
27ºC D
19ºC W
Total capacity kW
5.41
5.38
5.36
5.32
5.30
5.24
5.18
Input kW.
1.53
1.54
1.55
1.57
1.58
1.66
1.74
29ºC D
21ºC W
Total capacity kW
5.48
5.44
5.42
5.39
5.36
5.30
5.24
Input kW.
1.55
1.57
1.58
1.60
1.61
1.69
1.77
32ºC D
23ºC W
Total capacity kW
5.58
5.55
5.52
5.49
5.47
5.40
5.34
Input kW.
1.56
1.57
1.59
1.60
1.61
1.69
1.78
6.2 CCR-24HVR4
MODEL
CCR-24HVR4
COOLING
OUTDOOR TEMPERATURE DRY
Indoor Conditions
21ºC
25
28ºC
32ºC
35ºC
42ºC
49 ºC
21ºC D
15ºC W
Total capacity kW
6.82
6.78
6.75
6.71
6.68
6.61
6.35
Input kW.
2.02
2.04
2.05
2.07
2.09
2.19
2.30
24ºC D
17ºC W
Total capacity kW
7.04
7.00
6.97
6.92
6.89
6.82
6.74
Input kW.
2.04
2.06
2.08
2.10
2.11
2.22
2.33
27ºC D
19ºC W
Total capacity kW
7.25
7.21
7.17
7.13
7.00
7.02
6.94
Input kW.
2.07
2.09
2.10
2.12
2.14
2.25
2.36
29ºC D
21ºC W
Total capacity kW
7.34
7.29
7.26
7.22
7.19
7.11
7.03
Input kW.
2.10
2.12
2.14
2.16
2.18
2.29
2.40
32ºC D
23ºC W
Total capacity kW
7.48
7.43
7.40
7.35
7.32
7.24
7.16
Input kW.
2.11
2.13
2.15
2.17
2.18
2.29
2.41
6.3 CCR-36HVR4, CCR-36HVR4S
MODEL
CCR-36HVR4, CCRHVR4S
COOLING
OUTDOOR TEMPERATURE DRY
Indoor Conditions
21ºC
25
28ºC
32ºC
35ºC
42ºC
49 ºC
21ºC D
15ºC W
Total capacity kW
10.09
10.03
9.99
9.93
9.88
9.77
9.66
Input kW.
2.97
3.00
3.02
3.04
3.06
3.22
3.38
24ºC D
17ºC W
Total capacity kW
10.41
10.35
10.30
10.24
10.19
10.08
9.97
Input kW.
3.01
3.03
3.05
3.08
3.10
3.27
3.43
27ºC D
19ºC W
Total capacity kW
10.72
10.56
10.61
10.55
10.50
10.38
10.27
Input kW.
3.04
3.07
3.09
3.12
3.15
3.30
3.47
29ºC D
21ºC W
Total capacity kW
10.85
10.79
10.79
10.67
10.63
10.51
10.39
Input kW.
3.09
3.12
3.14
3.18
3.20
3.36
3.52
