2. Specification
Model CTA-18HVR4 CTA-24HVR4
Indoor power supply V/Ph/Hz 220~240/1/50 220~240/1/50
Cooling
Capacity KW 2.0-5.3-5.6 3.5-7.0-8.0
Power input W 420-1590-2100 650-2150-3050
Current input A 2.1-10.1 2.8-9.7-13.3
EER W/W 3.33 3.26
SEER W/W 6.1 6.1
Heating
Capacity KW 2.5-5.9-6.0 4.5-7.7-8.5
Input W 500-1475-1940 630-1925-2650
Rated current A 2.5-9.2 3.0-11.3
COP W/W 4.0 3.3
SCOP W/W 4 4
Energy rate Cooling A++ A++
Energy rate Heating A+ A+
Max. power input W 2400 3250
Max. current input A 11.4 14.5
Indoor fan
motor
Model DR-310-68F-8 DR-310-68F-8
Brand Panasonic Panasonic
Power output W 68 68
Speed r/min 1275/1080/880/720 1275/1080/880/720
Insulation class E E
Indoor coil
Number of rows 3*2 3*2
Tube pitch(a)xrow
pitch(b)
mm
21
×
12.7
21
×
12.7
Fin spacing
mm
1.4
1.4
Fin type Hydrophilic Hydrophilic
Tube outside dia. and
type
mm
Ф7 Ф7
inner grooved inner grooved
Coil
lengthxheightxwidth
mm
920
×
200
×
46 920
×
200
×
46
Number of circuits 6 6
Indoor air flow(High speed) m
3
/h 800/630/530 800/630/530
Static
Pressure
Rated Pa 0 0
Recommended Pa 0-30 0-30
Range* Pa 0-60 0-60
Indoor noise
level
Power level dB(A) 46~58
56
～
63
Pressure level dB(A) 36/40/45 43/45/47
Indoor unit
Dimension(W*H*D) Body(mm)
1214
×
210
×
467
1214
×
210
×
467
Packing(W*H*D) Body(mm)
1310
×
240
×
510
1310
×
240
×
510
Net/Gross weight Body(Kg) 22.5/25.5 25/28
Maxpressure MPa 4.2 4.2
Refrigerant
piping
Liquid side/Gas side mm Φ6.35/Φ12.7 Φ9.52/Φ15.88
Drainage pipe mm DN25 DN25
Standard controller Standard for remote controller(wired controller for option)
Operation temp of indoor
°
C
16
～
32
16
～
32
Ambient temp
heating °
C
-15
～
30
-15
～
30
cooling
°
C
-15
～
50
-15
～
50
