Chigo CCB-18HVR4 - Specification of Compact 4-Way Cassette

R3250Hz Universal Outdoor Series Technical Manual
18
GD Chigo Heating & Ventilation Equipment Co., Ltd.
2.2 Specification of compact 4-way cassette
Model CCB-18HVR4
Indoor power supply
V/Ph/Hz
220~240/1/50
Cooling
Capacity
KW
2.0-5.3-5.6
Power input W 420-1555-2100
Current input
A
2.1-10.1
EER
W/W
3.41
SEER
W/W
6.1
Heating
Capacity
KW
2.5-5.9-6.0
Input
W
500-1445-1940
Rated current
A
2.5-9.2
COP W/W 4.08
SCOP
W/W
4
Energy rate
Cooling
A++
Energy rate Heating A+
Max. power input
W
2400
Max. current input
A
11.4
Indoor fan
motor
Model
DR-310-35Q-8-1
Brand Shibaura
Power output
W
35
Speed
r/min
790
Insulation class E
Indoor coil
Number of rows
2
Tube pitch(a) x row pitch(b)
mm
21×13.37
Fin spacing mm
1.4
Fin type
Hydrophilic
Tube outside dia. and type mm
Ф7
inner grooved
Coil length x height x width
mm
1317x210x26.74
Number of circuits
4
Indoor air flow (High speed)
m
3
/h
650
Indoor
noise level
power level
dB(A)
46-55
pressure level
36/39/43
Indoor unit
Dimension (W*H*D)
Body(mm)
565x267x565
Panel(mm)
650x29.8x650
Packing (W*H*D)
Body(mm)
745x375x675
Panel(mm) 750x95x750
Net/Gross weight
Body(Kg)
16.5/21.5
Panel(Kg)
2.7/4.0
Max pressure MPa 4.2
Refrigerant type
R32
Refrigerant
piping
Φ6.35/Φ12.7 mm Φ6.35/Φ12.7
Drainage pipe DN25 DN25
Standard controller
Operation temp
°C
16
～
32
Ambient
temp
cooling
°C
-15
～
50
heating
°C
-15
～
30
