R3250Hz Universal Outdoor Series Technical Manual
54
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Model CTB-36HVR4 CTB-36HVR4S
Indoor power supply V/Ph/Hz 220~240/1/50 220~240/1/50
Cooling
Capacity KW 6.6-10.5-12.8 6.6-10.5-12.8
Power input W 830-3275-3900 830-3275-3900
Current input A 3.1-13.6-20 2.1-8.0-10
EER W/W 3.21 3.21
SEER W/W 6.1 6.1
Heating
Capacity KW 7.35-11.5-13.2 7.35-11.5-13.2
Input W 1200-3500-4000 1200-3500-4000
Rated current A 4.5-14.7-20.4 3-7.8-10.2
COP W/W 3.3 3.3
SCOP W/W 4.0 4.0
Energy rate Cooling A++ A++
Energy rate Heating A+ A+
Max. power input W 4800 4800
Max. current input A 26 10.3
Indoor fan
motor
Model DR-310-150F-8 + DR-310-75F-8 DR-310-150F-8 + DR-310-75F-8
Brand Panasonic Panasonic
Power output W 150+75 150+75
Speed r/min
1350/1240/1140/1040 +
1350/1270/1200/1130
1350/1240/1140/1040 +
1350/1270/1200/1130
Insulation class E E
Indoor coil
Number of rows 3 3
Tube pitch(a)xrow
pitch(b)
mm
22
×
19.05 22
×
19.05
Fin spacing mm 1.7 1.7
Fin type Hydrophilic Hydrophilic
Tube outside dia.
and type
mm
Ф7.94 Ф7.94
inner grooved inner grooved
Coil
lengthxheightxwidth
mm
1136
×
240
×
57.15 1136
×
240
×
57.15
Number of circuits 6 6
Indoor air flow(High speed) m
3
/h 1800/1500/1200 1800/1500/1200
Static
Pressure
Rated Pa 37 37
Recommended
Pa
30-50 30-50
Range*
Pa
0~120 0~120
Indoor noise level dB(A)
Power level
55
～
63
55
～
63
Pressure level 42/46/48 42/46/48
Indoor unit
Dimension(W*H*D) Body(mm)
1425
×
260
×
663
1425
×
260
×
663
Packing(W*H*D) Body(mm)
1490
×
325
×
720 1490
×
325
×
720
Net/Gross weight Body(Kg) 46/50 46/50
Maxpressure MPa 4.2 4.2
Refrigerant type R32 R32
Refrigerant
piping
Liquid side/
Gas side
mm Φ9.52/Φ15.88 Φ9.52/Φ15.88
Drainage pipe
mm
DN25
DN25
Standard controller Standard for remote controller(wired controller for option)
Operation temp °
C
16
～
32
16
～
32
Ambient
temp
heating
°
C
-15
～
30
-15
～
30
cooling °
C
-5
～
50
-5
～
50
