R3250Hz Universal Outdoor Series Technical Manual
GD Chigo Heating & Ventilation Equipment Co., Ltd.
1
Top cover plate parts
8
Repair board (with convex cover) with cotton
patch assembly
2 Electronic components 9 Chassis components
2.1 Outdoor inverter module integrated board 10 Front panel (with plastic mesh)
2.2 Terminal bedplate 11 Left side panel
2.3 Terminal 11.1 left side plate
2.4 Line pressing buttons 11.2 Small handle
3 median septum 12 The fan parts
4 Piping components 12.1 Motor support assembly
4.1 4-way valve assembly 12.2 Single shaft outdoor DC motor
4.2 throttling parts 12.3 Axial-flow fan
4.3 Electronic expansion valve coil 12.4 The fan pressing plate
5 Right side panel 13 Condenser unit
5.1 Right board pasted cotton component 13.1 Condenser assembly
5.2 Large hand-drawn cotton patch assembly 13.2 Manifold assembly
6 The seat plate 13.3 Shunt capillary assembly
7 inverter compressor 14 Back mesh connection Angle
