R3250Hz Universal Outdoor Series Technical Manual
15
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Model CCR-36HVR4 CCR-36HVR4S
Indoor power supply
V/Ph/Hz
220~240/1/50
220~240/1/50
Cooling
Capacity
KW
6.6-10.5-12.8
6.6-10.5-12.8
Power input W 740-3150-3900 740-3150-3900
Current input
A
2.8-13.6-20
1.8-8.0-10
EER
W/W
3.33
3.33
SEER
W/W
6.1
6.1
Heating
Capacity
KW
7.35-11.5-13.2
7.35-11.5-13.2
Input
W
1100-3375-4000
1100-3375-4000
Rated current
A
4.2-14.7-20.4
2.8-7.8-10.2
COP W/W 3.09 3.09
SCOP
W/W
4.0
4.0
Energy rate
Cooling
A++
A++
Energy rate Heating A+ A+
Max. power input
W
4800
4800
Max. current input
A
26
10.3
Indoor fan
motor
Model
DR-310-100Q-8
DR-310-100Q-8
Brand
Panasonic
Panasonic
Power output
W
100
100
Capacitor
μF
-
-
Speed r/min 840/750/650 840/750/650
Insulation class
E
E
Indoor coil
Number of rows
2
2
Tube pitch(a) x row pitch(b) mm
21×13.37 21×13.37
Fin spacing
mm
1.45 1.45
Fin type
Hydrophilic
Hydrophilic
Tube outside dia. and type mm
Ф7
Ф7
inner grooved
inner grooved
Coil length x height x width
mm
2000×252×26.74 2000×252×26.74
Number of circuits
12
12
Indoor air flow (High speed) m
3
/h 1800/1700/1550 1800/1700/1550
Indoor
noise level
power level
dB(A)
53
～
61
53
～
61
pressure level
43/45/48
43/45/48
Indoor unit
Dimension (W*H*D)
Body(mm) 840×285×840 840×285×840
Panel(mm)
950×50×950
950×50×950
Packing (W*H*D)
Body(mm)
920×310×920
920×310×920
Panel(mm)
1030×105×1030
1030×105×1030
Net/Gross weight
Body(Kg)
30.5/36
30.5/36
Panel(Kg)
6.5/9.5
6.5/9.5
Max pressure
MPa
4.2
4.2
Refrigerant type R32 R32
Refrigerant
piping
Liquid side/Gas side mm Φ9.52/Φ15.88 Φ9.52/Φ15.88
Drainage pipe
mm
DN25
DN25
Standard controller
Standard for remote controller(wired controller for
option)
Operation temp
°C
16
～
32
16
～
32
Ambient
temp
cooling °C
-15～50 -15～50
heating
°C
-15
～
30
-15
～
30
