R3250Hz Universal Outdoor Series Technical Manual
38
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No. Part Name No. Part Name
1
E-parts box cover
5.4.3
Current collecting assy for
evaporator
2
Eletric control components for
indoor unit
5.4.4
Current divider capillary assy for
evaporator
2.1
Reactor
6
Upper foam components
2.2
Capacitor board
7
Water pump components
2.3
Terminal
7.1
Water pump fan motor holder
2.4
E-parts board for indoor unit
7.2
Water pump
2.5
Temperature sensor group
7.3
Underlay for water pump support
2.6
Welded chasis for E-parts box
8
Wind wheel clasp
3
Wind inlet guide assy
9
Centrifugal fan
3.1
Wind inlet guide
10
Fan motor for indoor
unit(YDK-45Q-6P2)
4
Water pan
11
Rear brattice
5
Evaporator components
12
Chassis assy
5.1
Insulating pipe
13
Auxiliary fixing board for
evaporator
5.2
Insulating pipe
14
Front brattice
5.3
Insulating pipe
15
Hanger
5.4
Evaporator welding assy
16
Discharge pipe joint
5.4.1
Instalation tube for probe
17
Side maintenance board for water
pump
5.4.2
Evaporator
18
Valve panel
