R3250Hz Universal Series Technical Manual
85
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Model
CUA-36HVR4
CUA-36HVR4S
Indoor power supply
V/Ph/Hz
220~240/1/50
220~240/1/50
Cooling
Capacity KW 6.6-10.5-12.8 6.6-10.5-12.8
Power input
W
740-3170-3900
740-3170-3900
Current input
A
2.8-13.6-20
1.9-8.0-10
EER W/W 3.31 3.31
SEER
W/W
6.1
6.1
Heating
Capacity
KW
7.35-11.5-13.2
7.35-11.5-13.2
Input W 1100-3395-4000 1100-3395-4000
Rated current
A
4.2-14.7-20.4
2.8-7.8-10.2
COP
W/W
3.39
3.39
SCOP
W/W
4.0
4.0
Energy rate
Cooling
A++
A++
Energy rate
Heating
A+
A+
Max. power input
W
4800
4800
Max. current input A 26 10.3
Indoor fan
motor
Model
DR-310-120LD-8
DR-310-120LD-8
Brand
Panasonic
Panasonic
Power output W 120 120
Capacitor
μF
-
-
Speed
r/min
1400
1400
Insulation class
E
E
Indoor coil
Number of rows
3
3
Tube pitch(a)xrow
pitch(b)
mm 21×13.37 21×13.37
Fin spacing
mm
1.4
1.4
Fin type
Hydrophilic
Hydrophilic
Tube outside dia.
and type
mm
Ф7
Ф7
inner grooved
inner grooved
Coil length x height x
width
mm 1000x252x40.11 1000x252x40.11
Number of circuits
4
4
Indoor air flow (High speed) m
3
/h 1800/1650/1500 1800/1650/1500
Indoor noise
level
power level
dB(A)
56
～
65
56
～
65
pressure level
45/48/51
45/48/51
Indoor unit
Dimension (W*H*D)
Body(mm)
1245×680×240
1245×680×240
Packing (W*H*D)
Body(mm)
1325×770×325
1325×770×325
Net/Gross weight
Body(Kg)
35/41
35/41
Max pressure
MPa
4.2
4.2
Refrigerant type R32 R32
Refrigerant
piping
Liquid side/Gas side mm Φ9.52/Φ15.88 Φ9.52/Φ15.88
Drainage pipe
mm
DN25
DN25
Standard controller Standard for remote controller(wired controller for option)
Operation temp
°C
16
～
32
16
～
32
Ambient temp
cooling
°C
-15
～
50
-15
～
50
heating °C
-15～30 -15～30
