4 Connections

4.1 Connections overview

The VariPro room controller is intended for use with the VariPro controller card.

The controller card is compatible with GRAND VariPro, BOX VariPro and

STUDIO VariPro units.

Note! Project-specific wiring diagrams are always provided with the fan coil unit.

4.2 Connections between the VariPro room

controller and the fan coil units

There are two ways to connect a VariPro room controller. Both connection

terminals are factory-installed on the controllers and units.
