8 Controller menus
8.1 Main menu
1. Main menu
2. Change the language of the menu. Options are
English and Finnish.
3. See Section
8.2 Energy menu / Fan energy
4. See Section 8.3 Service menu
5. See Section 8.4 Unit settings
6. See Section 8.6 Controller settings
7. See Section 8.7 Modbus
8. See Section 8.8 Alarms
9. See Section 8.9 Testing
10. See Section 8.10 Screen
11. Exit the menu.
8.2 Energy menu / Fan energy
1. Heat transfer energy menu (only available with
pressure independent valves)
2. Calculated heat transfer energy
3. Estimated monthly/annual heat transfer energy
4. Fan energy menu
5. The fan’s calculatory electricity consumption
6. The fan’s estimated monthly/annual electricity
consumption
The Heat transfer menu (settings 1–3) is shown only if the flow data is
available and the temperature sensors are connected to water pipes.
The Fan energy (settings 4–6) menu is shown only if the electricity consumption
of the fan controlled by the CC card is available.
Copyright © 2021. All rights reserved.
25 (37)
N03104128 Rev. A VariPro Room controller – Installation and Operation Manual
