Chiptech SEVEN - 4G PERS - Underside

SPECIALISTS IN DIGITAL TELECARE
5
chiptech.co.nz
2.2 Underside
Screw
Slot
Ethernet Connection
For communicating
to monitoring, and
located in the cable
cavity.
SIM Card Holders
SEVEN has two micro SIM
card holders, and these
are located under the
battery pack.
Power connection
9V DC
Battery Compartment
This contains one
rechargeable battery
pack, with an expected
battery life of up to five
years.
Backup battery life is up
to 70 hours.
The label placed here
contains standards.
To Wall Mount
Use the two available
screw slots to mount
SEVEN to the wall or wall
mount bracket.
Expansion Card Slot
An expansion card can be fitted to provide
additional functions. This is located under the
battery pack.
Option Port
This port is used to
connect to a
computer for
programming via the
Chiptech Wizard
Microphone – Part of the hands-free
speakerphone system.
Screw
anchor
Slot
Under glow lights
These are aesthetic
and dim to adjust to
the environmental
lighting in a room.
