Broadcaster Wiring

MT2461A

Ethernet Cat 5e-6 (CT3 and other Chore-Tronics Controls) Wiring

Ethernet Cable

Alarm Inputs to Broadcaster (Twisted Pair)

Fnet

CT3 Controls send specific Alarms directly

to the Broadcaster Main Box

ELT

Ethernet Cable

Broadcaster

Aux Box

Broadcaster

Main Box

8 dry Contact Inputs

CT3 Main Box

Internet Router

Ethernet Switch

Ethernet Cable

CT3 Main Box

Ethernet Switch

(8 dry contact inputs)

Ethernet Switch
