Broadcaster Installation
9
MT2461A
Mounting the Control
Before Setting up the Broadcaster, it will have to be disarmed.
1.Press the 3 and 9 button simultaneously and release. The Current Condition Screen will display "Disarmed".
2.Arm the Broadcaster after you have completed all the Setup.
3.Test the Modems by sending a Dial Test and send a test alert from the Controls.
4.Saving the current installed Modems must be done before continuing with the setup of the Broadcaster.
Cellular Modem Setup
1.From the Current Conditions screen, press the Back Button. Select Setup from the Main Menu.
2.Select General from the Setup Menu.
3.Scroll down to Cell Modem Config and select.
4.The current installed Cell Modem will be displayed. Press the 1 and 7 Button to save.
5.Select Yes and press Edit.
6.Press the 1 and 7 Button to save.
Installation
Disarming the Broadcaster
2461-006 11/2016
Figure 5.Mounting the Control
18" [45.7cm]
11-3/4" [29.8cm]
Telephone
Cellular
Antenna
Ethernet Port (A)
Ethernet Port (B)
Power Supply
Jack Line In
Telephone Jack(B)
1) 2) 3)
4)
5)
