16
| INSTALLATION MANUAL PRORAPID
Description Slc
Specications
Electrical specications:
Power supply 100 - 240VAC, 50 - 60 Hz
Power consumption / standby 0,5W - 2,5W/ X
Internal fuse 1 2A slow blow 250V
Protection Class IP40
Protection Class II
Overvoltage category II
Degree of pollution category II
Inputs/Outputs
Sensor inputs 6 -40 °C ... 300 °C
Outputs mechanical relay 3
mechanical relay R1 - R3 460VA for AC1 / 460W for AC3
0-10V/PWM output V1 - V2 for 10 k Ω working resistance 1 kHz, level 10 V
Max. cable length
Flow sensors <3m
0-10V/PWM <3m
mechanical relay <10m
Permissible Ambient Conditions
for controller operation 0 °C - 40 °C, max. 85 % rel. humidity at 25 °C
for transport/storage
0 °C - 60 °C, no moisture condensation
permitted
Other Specications and Dimensions
Housing design 2-part, ABS plastic
Installation methods Wall installation, optionally panel installation
Overall dimensions 163 mm x 110 mm x 52 mm
Aperture installation dimensions 157mm x 106mm x 31mm
Display completely graphic display 128 x 64 dots
Real Time Clock RTC with 24 hour power reserve
Operation 4 entry keys
