1. Measurement values
Serve to display the current measured
temperatures.
!
If ‚error‘ appears on the
display instead of the
measurement value, there
may be a defective or
incorrect temperature
sensor.
!
If the cables are too long
or the sensors are not well-
placed, small deviations in
the measurement values
may occur. In this case, the
display values can
be compensated by
adjustments in the controller
- see ‚Sensor calibration‘.
The selected program,
connected sensors
and the specic model
design determine which
measurement values
are displayed.
Exit measurements
1.2 Hot water
1.1 Hot water
65ºC
45ºC
2. Operation mode
Auto
The automatic mode is the normal mode
of the controller. A correct controller
function under consideration of the current
temperatures and the set parameters is
only present in automatic mode! After
an interruption of the mains voltage, the
controller automatically returns to the last
operating mode selected.
Manual
The individual relay outputs, v outputs
and the connected consumers can be
checked for proper functioning and correct
assignment.
Exit operating mode
3.2 Manual
3.1 Auto
�
Info
