HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.65 D
5
Horizontal package air conditionners
HCompact2 HA
4. UNIT IDENTIFICATION
All units bear, legibly and indelibly, a data plate located in a prime space,
as appears in the attached image. Check that this plate matches the
correct model.
Check the condition of the equipment upon delivery.
Check that the details on the label, the packing and the data plate
match the order.
If equipment has been damaged, or there is a shortfall in delivery,
notify accordingly.
V-220005
V-220004
5. SAFETY ADVICE
These units work with refrigerant gas R-410A. This fl uid is used up to
a maximum service pressure of 42 bar.
Refrigerant leaks:
A periodical check must be performed for refrigerant gas leaks as
per Regulation (CE) Nº517/2014 over certain greenhouse effect
fl uoride gases. Please, consult the frequency of checks in chapter of
“Maintenance”.
Important: The serial number must be used in all
communications regarding the unit.
Ref. Produit\Item Nbr Designation\Description
An.Y
ear
No Serie\Serial Nbr \ No Produit
Refrigerant kW Absorbee\Input kW Poids\Weight
Refrigerant kg Tension\Voltage Temper
ature Maxi C
BP Mini PSM\MOP Intensité\Current A IP
HP Maxi PSM\MOP Int.. Kit Elect. No CE
30, av JeanFalconnier
01350 CULOZ
Tel : 33(0)4 79 42 42 42
Made in Spain
Refrigerant type
Low pressure
Model
Order Nbr
Weight in operation
Line voltage
High pressure
Manufacturing Nbr
Electrical kit current
To avoid any risk of accident during installation, commissioning or
maintenance, it is obligatory to take into consideration the following
specifications for the units: refrigerated circuits under pressure,
refrigerant presence, electrical voltage presence and implantation place.
Because of all of this, only qualifi ed and experienced personnel can
perform maintenance tasks or unit repairs.
It is required to follow the recommendations and instructions
in the maintenance brochures, the labels, and the specifi c
instructions.
It is necessary to comply with the norms and regulations
in effect. It is recommended to consult the competent
authorities regarding the applicable regulations for users
of units or components under pressure. The characteristics
of these units or components are included on the plates of
characteristics or in the regulatory documentation provided
with the product.
The compressor and line surfaces can reach temperatures
above 100ºC causing burns to the body. In the same fashion,
under certain conditions these surfaces can reach very cold
temperatures that can cause freezing risks.
Use safety goggles and gloves on the job. Be careful with
sharp parts or elements in the unit.
Caution: Before intervening in the unit, verify that the main
power to the unit is cut off. An electric shock can cause
personal damage.
Note: In order to recycle these units follow the stipulations
of Directives (EC) No. 96/2002 and No. 108/2003 regarding
electrical and electronic equipment and the management of
the resulting waste.
In case of a leak:
- Toxicity: According to ASHRAE 34, R-410A belongs to the A1/A1 group,
i.e. with high safety both in the mix and also in the case of a leak.
- Although it is not toxic, in case of a leak to atmospheric pressure the
liquid phase evaporates. The resulting vapours are heavier than air
and can displace the technician local air. In case of an accidental
discharge in a closed enclosure, fans must be used to eliminate said
vapours.
- Although the R-410A is not fl ammable, when in contact with a fl ame
o hot spot it can decompose in fl uorhydric acid HF and fl uophosgene
COF
2
highly toxic and corrosive.
- To detect leaks, an electronic leak detector, an ultraviolet lamp or
soapy water must be used. Flame detectors do not help.
Important: Immediately repair any refrigerant leak, using
a recovery unit specifi c for R-410A that avoids a possible
mixture of refrigerants and/or oils.
Components of the R-410A R-32 R-125
Chemical formula
CH2F2 CHF2CF3
Weight ratio
50% 50%
Unitary global warming potential (GWP)
675 3.500
Global warming potential (GWP)
2.088
