CIGWELD 200i - Tweco Fusion 250 Mig Torch

TRANSMIG 200i
KEY SPARE PARTS 6-2 Manual 0-5209
6.02 Tweco Fusion 250 Mig Torch
MIG Torch Part No: W4013701
A-09659
21 43
7
55
7
6
7
8
TWECO FUSION MIG TORCH PARTS
ITEM PART NO. DESCRIPTION
1
OTW22/50 Nozzle 13mm
OTW22/62 Nozzle 16mm
2
OTW14/23 Contact Tip 0.6mm
OTW14/30 Contact Tip 0.8mm
OTW14/35 Contact Tip 0.9mm
OTW14/40 Contact Tip 1.0mm
OTW14/45 Contact Tip 1.2mm
3 OTW32 Insulator
4 OTW52 Gas Diffuser
5 62J-45S Conductor Tube, 45 Degree
6 W7005001 Trigger Assembly
7 W7005000 Handle Mouldings
8
OTW42/3035 Liner 0.8-0.9mm Hard Wire
OTW42/4045 Liner 1.0-1.2mm Hard Wire
OTW42N/3545 Liner 0.9-1.2mm Soft Wire
Table 6-2
