91
Model Designation
8400 8470
Bluetooth Class 2 √ √ Wireless
Communications
802.11b/g √
Readers Barcode Reader
CCD (linear imager)
Standard Laser
2D Imager
Main Battery Rechargeable Li-ion battery – 3.7 V, 1800 mAh
Working Time Laser, one scan per 5 seconds, without backlight:
110 hours in batch mode
35 hours in Wi-Fi mode
65 hours in Bluetooth mode
Backup Battery
Rechargeable Lithium button cell – 3.0 V, 18 mAh
Data retention – at least 25 days
Electrical
Characteristics
Power Adaptor
Input: AC 100~240 V, 50/60 Hz
Output: DC 5 V, 3 A
Operating Temperature: 0 °C to 40 °C
CPU 32-bit Toshiba CMOS type, 60 MHz
Memory
Program memory – 4 MB flash
Data memory – onboard SRAM, options include 4
or 16 MB
Display Graphic LCD, 160 x 160 pixels, FSTN with LED
backlight programmable
Font size 6x8: 26 characters by 18 lines
Font size 8x16: 20 characters by 9 lines
Font size 12x12: 13 characters by 12 lines
Font size 16x16: 10 characters by 9 lines
Keypad 29 or 39 rubber keys, LED backlight programmable
Indicators
Two dual-color LEDs – red/green and blue/green,
programmable
Buzzer – 2.7 KHz, programmable
Vibrator 0.45G, programmable
Expansion Slot microSDHC, up to 8 GB
Enclosure Material Rubber & ABS plastic
Dimensions 171 mm (L) 72 mm (W) 41 mm (H)
Physical
Characteristics
Weight Approx. 295 g (Laser, battery included)
SPECIFICATIONS
