51
Chapter 3 System Menu
SETTINGS
Interface
Options Description
RS232 Proceed to configure baud rate settings on your computer and the
mobile computer.
USB VCOM Connect the USB cable between your computer and the mobile
computer.
Bluetooth Approach the target Bluetooth enabled device.
SD Card This option is available only when the memory card is present.
Baud Rate
Options Supported by CipherLab software, including download utilities
115200 (bps) Yes
76800 (bps) No
57600 (bps) Yes
38400 (bps) Yes
19200 (bps) Yes
9600 (bps) Yes
4800 (bps) No
2400 (bps) No
LOAD PROGRAM VIA BLUETOOTH
1) Go to System Menu | 7. Bluetooth Menu | 3. Security, and configure the
following Bluetooth settings first.
Authentication
PIN code
2) Go to System Menu | 6. Load Program and select Bluetooth.
3) Start the pairing procedure from your computer, for example, click [Pair Device]
and/or [Connect Bluetooth Serial Port].
4) Run the download utility: ProgLoad.exe
- Select interface RS-232 for using Bluetooth SPP.
- Select COM port properties that match with the serial port settings used on your
computer.
