29
STEP 4:
Release 2 adjustment screws
on the front and rear motor
boundary via two M14
wrenches.
STEP 5:
Push the motor to front roller
and split the belt from the
motor output shaft pulley.
STEP 6:
Remove 2 front roller
mounting screws using an M6
Wrench.
