30
STEP 7:
Lift up the front roller on
pulley side and remove the
drive belt from the front
roller.
STEP 8:
Remove the roller cover by
unscrewing the 4 screws
on both sides.
STEP 9:
Remove the end cap set
plate by unscrewing the 4
screws on both sides.
