32
STEP 13:
Remove the 4 deck screws at 4
corners via the Philips
screwdriver
STEP 14:
Remove the front roller from
the running belt.
Remove the rear roller from
the running belt
STEP 15:
Remove running deck from
one side and replace new
running belt.
Be aware of sharp edge of
running deck, wearing gloves
at work is suggested.
To install new running belt,
place new belt with transverse
direction and insert new deck
through the running belt.
Install new running belt and
deck locate on deck cushion
and rubber cushion.
Lock and secure the deck with
deck screws at 4 corners.
