36
STEP 4:
Release 2 adjustment
screws on the front and
rear motor boundary via
two M14 wrenches.
STEP 5:
Push the motor to front
roller and split the belt from
the motor output shaft
pulley.
STEP 6:
Remove 2 front roller
mounting screws using an
M6 Wrench.
