14
computer MAX
Instruction Manual
COM 7 8 9 10 11 12
COM
0
1 2 3 4 5 6A B
S1 S2
C D
RELAYS C1..C6
RELAYS C7..C12
SUPPLY AND MEASURE
TERMINALS
V
P1 P2
Figure 5: Computer MAX 12�
Note: For computer MAX 12 devices (12 relay outputs) the connection between COM termi-
nals in the upper and lower terminal strips must be done externally.
