Instruction Manual
computer MAX
8�- TECHNICAL FEATURES
AC Power supply
Voltage measurement circuit
Connection ConnectpreferablytophasesL2-L3
Rated voltage
480V
~ , 400V~, 230V~ o 110 V ~
+15%-10%(dependingonmodel)
Frequency 45...65Hz
Consumption
110 V
~ 230 V~ 400 V~ 480 V~
7 ... 10 VA 7.4...9.9VA 5 ... 8.8 VA 8.7 ... 10.7 VA
Installation category CATIII300V
Current measurement circuit
Connection Connect preferably to phase L1
Rated current (In) .../5A
Current measurement margin 0.05...5A(Maximumoverload+20%)
Installation category CATIII300V
Measurement accuracy
Voltage measurement 1 %
Current measurement 1 %
cos φ measurement 2 % ± 1 digit
Relays outputs
Quantity
computer MAX 6 computer MAX 12
6 12
Max� voltage open contacts 250V ~
Max� current ( 1 relay ) 6 A~ , AC1
Max� current (Terminal connection) 12 A~
User interface
Display 3digits,7segments+20icons
Keyboard 3keys
LED 2 LED
Environmental features
Operating temperature -20ºC...+60ºC
Storage temperature -20ºC...+70ºC
Relative humidity (non-condensing) 5 ... 95%
Maximum altitude 2000 m
Protection degree
IP30
Frontpanel:IP40
Mechanical features
Dimensions (Figure7) 144x144x62.5mm
Weight 56 gr
Surround Self-extinguishing V0 plastic
Attachment Panel
Insulation
Protection against electrical shock with
doubleinsulation(deviceClaseII)accordingtoEN61010-1
Standard
Safety requirements for electrical equipment for measurement UNE EN 61010 : 2010
